Wuxi Junda Electromechanical Manufacturing Co., Ltd.

PURPOSE:
The grid format plate type cleaning machine is mainly used as a filtering and cleaning equipment in power plants,urban watersupply,municipal water supply and drainage,metallurgy,chemical engineering,and other projects.I isused in conjunction with theupstream trash rack,which can effectively intercept and remove various types of smaller pollutants such as aquatic organisms,aquatic plants,algae,branches,and thin films in the water fow

COMPOSE:
The grid format plate type ceaning machine is mainly composed of a rack containing guide rails,transmission system,tractionchain,mesh plate,lower frame and guide rails,flushing water system,sewage collection tank,safety protection device,and otherparts. 工作原理OPERATING PRINCIPLE:

OPERATING PRINCIPLE:
Driven by an electric motor,the transportation chain uses a mesh plate connected to i by bolts to perform self rotating motion.Use a mesh plate to intercept the dirt in the water flow in front of the mesh and lift it above the ground(zero meter layer).Throughpressure water flushing,collect the dirt on the mesh plate into the slag flushing tank to filter the water quality.
